Q-See 32 Channel 1080P HD IP NVR Security System with 4TB Hard Drive, 12 3MP IP Bullet Cameras, and 4 3MP IP Dome Cameras
Electronics & Computers
Security & Surveillance
Q-See 32 Channel 1080P HD IP NVR Security System with 4TB Hard Drive, 12 3MP IP Bullet Cameras, and 4 3MP IP Dome Cameras
Q-See 32 Channel 1080P HD IP NVR Security System with 4TB Hard Drive, 12 3MP IP Bullet Cameras, and 4 3MP IP Dome Cameras
by Q-See
|
Item #: 769097
|
Model #:
QT8716-16AA-4
|
Free shipping
- $299 off with Tech Savings
-
Offer ends April 03
- Tech Savings items are limited to select items, availability, valid dates and limits per membership. Select Tech Savings are available online and in club. State and local laws may require sales tax to be charged on the pre-discounted price of an item with a Tech Savings offer. Available in the U.S., excluding Puerto Rico.
- Member price $2999.00
- Tech Savings -$299.00
- $ 2,700 00
- Shipping
- Free shipping
- Enter ZIP Code for shipping options
Delivery estimates, taxes, and fees are based on ZIP Code. Club Pickup orders are based on your club’s current price and item availability on the day of payment.
About this item
- High Definition 3MP/1080P Recording
- iPhone/iPad, Android Apps
- 16 POE Ports (can expand up to 32 cameras)
- Durable casing with IP66 Weatherproof Rating and cable threaded through 3-Axis Mount
- For additional / replacement cameras please refer item: 122319 (model# QTN8037B) or item: 769160 (model# QTN8038D).
Description
Cover all the angles in 3MP video
This NVR/IP camera combination from Q-See punches way above its weight class! The heart of the system is the QT8716 NVR with a pre-installed 4TB hard drive. It’s ready-to-go straight out of the box and has plenty of room to grow from there. The camera POE ports provide plug-and-play connectivity for up to 16 of the included IP cameras and the NVR can support another 16 connected over a local network or the Internet. Another seven hard drives can be installed into the NVR for up to 32TB of internal storage. And, the QT8716 is ready to work the included 3MP cameras for better-than-1080p clarity.
3MP video – better than 1080p
Sixteen cameras are included in this package, including 8 varifocal units which can be tasked to cover a wider area or just a specific location. They capture video in 3 megapixel resolution compared to the 2MP resolution of 1080p. Each camera is weather proof to provide reliable service rain or shine as well as day or night. When the sun goes down, the built-in infrared LEDs invisibly illuminate the area – up to 165 feet, depending on the model - under surveillance. In addition to sending video to the NVR, cameras connected to a network can be directly accessed using Q-See’s free computer or mobile apps for instant situational awareness.
Peace of Mind – Anywhere, Anytime.
Q-See surveillance systems are designed to meet your home and business needs with easy installation and operation, so you can monitor your premises right away. Peace of Mind — Anywhere, Anytime.
Specifications
| System | |
|---|---|
| Number of Cameras: | 16 3MP Cameras (8 Fixed, 4 Bullet & 4 Dome Varifocal) |
| Number of Channels: | 32 |
| Number of POE Ports: | 16 |
| Hard Drive Space: | 4TB |
| Wired or Wireless: | Wired |
| Average Minimum Setup Time: | 4 Hours |
| DVR | |
| DVR Model: | QT8716 |
| Number of Channels: | 32 |
| Number of Channels with Audio: | 1 RCA, 16 via IP Camera |
| Hard Drive Size: | 4TB |
| Maximum Hard Drive Expandability: | 8 Drives up to 4TB Each |
| Recording Resolution: | 2048x1536 (3MP), 1920x1080 (1080P), 1280x720 (720P) |
| Recording Frames per Second: | 30FPS/3MP, 30FPS/1080P, 30FPS/720P, |
| Recording Compression: | H.264 |
| Recording Modes Available: | Continuous, Scheduled, Motion |
| Wireless Camera Receiver: | Not Available |
| Video Motion Detection Recording: | Yes |
| Pre-Event Recording/Capacity: | Not Available |
| Mobile App Viewing: | iPhone, iPad, Android |
| E-Mail Alert Notification: | Yes |
| Maximum Number of Remote Viewers: | 128 (Bandwidth Permitting) 20 |
| Playback and Search Options: | 2x, 4x, |
| Data Backup Options: | USB Flash drive, USB Portable Hard Drive |
| Digital Zoom: | Yes |
| Pan-Tilt-Zoom Controls: | Yes, Supported through CAT5e Cable, PTZ Camea not included |
| Still Frame Capture: | Yes |
| Alarm Terminal Trigger Recording / # of Inputs: | Yes, 4 |
| External Alarm Output Contact(s): | Not Available |
| Operating System: | NTSC |
| Included Accessories: | IR Remote Control, Mouse, CMS Software, Quick Start Guide |
| Camera Cable Connection Type: | RJ-45 |
| Compatible Cameras: | Any QTN Series IP Cameras |
| DVR Dimensions: | 16.75"x17.75x3.5" |
| Camera 1 | |
| Camera Model and Type: | QTN8037B 3MP IP Bullet Camera |
| Number of Cameras: | 8 |
| Image Sensor Type: | CMOS |
| TV Lines: | 3 Megapixel |
| Resolution: | 3MP/1080P |
| Effective Pixels: | 2048x1536 |
| Aperture: | F1.2 |
| Focal Length (35mm Equivalent): | 3.6mm |
| Pan-Tilt-Zoom Capability: | Not Available |
| Optical Zoom: | Not Available |
| Angle of View: | 65° to 70° |
| Color or Black and White: | Color- Day Black and White- Night Vision |
| Wireless Camera-DVR Connection: | Not Available |
| Audio Capability: | Not Available |
| Number of Infrared LEDs: | 30 |
| Night Vision Distance: | 100' |
| Recommended for Outdoor Use: | Yes |
| Weather Resistance (IP Rating): | IP66 |
| Operating Temperature: | Negative 4°F to 122°F |
| Operating Humidity: | 10-95% |
| Tamper Protection: | Not Available |
| Compatible DVRs: | Q-See QT Series NVR |
| Compatible Cables and Connector Type: | Cat5E |
| Length of Cable Included: | 100' |
| Camera Dimensions: | 2.5"W x 7.25"D x 2.5"H |
| Camera 2 | |
| Camera Model and Type: | QTN8039B 3MP Varifocal IP Bullet Camera |
| Number of Cameras: | 4 |
| Image Sensor Type: | CMOS |
| TV Lines: | 3 Megapixel |
| Resolution: | 3MP/1080P |
| Effective Pixels: | 2048x1536 |
| Aperture: | F 1.6 |
| Focal Length (35mm Equivalent): | 2.8mm-12mm-( Varifocal Lens) |
| Pan-Tilt-Zoom Capability: | Not Available |
| Optical Zoom: | Not Available |
| Angle of View: | 24° to 81° |
| Color or Black and White: | Color- Day, Night Black and White |
| Wireless Camera-DVR Connection: | Not Available |
| Audio Capability: | with added microphone |
| Number of Infrared LEDs: | 48 |
| Night Vision Distance: | 165' |
| Recommended for Outdoor Use: | Yes |
| Weather Resistance (IP Rating): | IP66 |
| Operating Temperature: | Negative 4°F to 122°F |
| Operating Humidity: | 10-95% |
| Tamper Protection: | Not Available |
| Compatible DVRs: | All QTN Series NVR |
| Compatible Cables and Connector Type: | Cat. 5e |
| Length of Cable Included: | 100' |
| Camera Dimensions: | 4.25"W x 11.25"L x 4.25"H |
| Camera 3 | |
| Camera Model and Type: | QTN8040D 3MP Varifocal IP Dome Camera |
| Number of Cameras: | 4 |
| Image Sensor Type: | CMOS |
| TV Lines: | 3 Megapixel |
| Resolution: | 3MP/1080P |
| Effective Pixels: | 2048x1536 |
| Aperture: | F 1.6 |
| Focal Length (35mm Equivalent): | 2.8mm - 12mm-(Varifocal Lens) |
| Pan-Tilt-Zoom Capability: | Not Available |
| Optical Zoom: | Not Available |
| Angle of View: | 24° to 81° |
| Color or Black and White: | Color- Day Black & White Night |
| Wireless Camera-DVR Connection: | Not Available |
| Audio Capability: | with added microphone |
| Number of Infrared LEDs: | 30 |
| Night Vision Distance: | 100' |
| Recommended for Outdoor Use: | Yes |
| Weather Resistance (IP Rating): | IP66 |
| Operating Temperature: | Negative 4°F to 122°F |
| Operating Humidity: | 10-95% |
| Tamper Protection: | Not Available |
| Compatible DVRs: | All QTN Series NVR |
| Compatible Cables and Connector Type: | Cat5e |
| Length of Cable Included: | 100' |
| Camera Dimensions: | 4.25"W x 11.25" L x 4.25"H |
| Technical Support | |
| Phone Number: | 1-877-994-3440 |
| Hours of Availability: | 6am-7pm Pacific time zone, Mon-Fri |
| Web Support URL: | http://www.q-see.com/support |
| Package Contents | |
| QT8716-NVR | |
| 4 TB Western Digital Purple Hard Drive | |
| USB Mouse, Remote Control | |
| Power Supply for NVR | |
| 8x QTN8037B 3MP IP Bullet Cameras | |
| 4x QTN8039B 3MP Varifocal IP Bullet Cameras | |
| 4x QTN8040D 3MP Varifocal IP Dome Cameras | |
| 16 X QS100N- Cat5e Camera Cables | |
| Power Supply for DVR | |
| Quick Start Guide | |
Assembled Country
China
Component Country
Imported
